Valve switch
Valve switch
Valve switch
Valve switch

Valve switch

Functions:

Control the stop or start of the material flowing through the switch of the gate, and control the flowing volume  of the material through the screw adjustment.

Send Email Contact us

Advantages

  • Compact structure, beautiful and elegant;
  • Optional manual, pneumatic, manual /pneumatic, electric and other types;
  • Available in stainless steel and carbon steel versions;
  • It can be processed and customized according to the required size.

Parameter

Model

Working pressure (Mpa)

Cylinder diameter (mm)

Gate thickness (mm)

Overall dimensions (mm)

TZMSQ15x15

0.6

φ40

4

520x210x100

TZMSQ20x20

0.6

φ50

4

622x260x110

TZMSQ25x25

0.6

φ50

4

722x310x110

TZMSQ30x30

0.6

φ50

4

822x360x110

TZMSQ40x60

0.6

φ63

4

1080x480x150

TZMSQ60x60

0.6

φ80

4

1480x680x150
