Roller mill
Roller mill
Roller mill
Roller mill
Roller mill
Roller mill

Roller mill

Functions:

Materials of different fineness are broken through alloy casting rollers with different speed differences and different wire drawing widths.

It is widely used in flour mills, alcohol factories, food factories and other enterprises.

Advantages

  • The solid casting base provides a solid foundation for the stable and efficient operation of the roller mill machine;
  • High standards of food safety and hygiene. Parts in contact with materials are made of food-grade stainless steel or food-grade materials;
  • Rotary feeding module. The rotatable feeding module facilitates cleaning of materials in the feeding bin and prevents material residue;
  • Integral assembly and disassembly of the grinding roller group. Quick roll change to reduce downtime;
  • Photoelectric material level sensor. Stable performance, little affected by material properties and environmental factors, easy to achieve digital control;
  • Monitoring of grinding roller separation. Set the grinding roller away from rolling position sensor to prevent the grinding roller from continuing to grind materials when there is no material;
  • Monitoring of grinding roller speed. Set up a grinding roller speed monitoring sensor to monitor the working condition of the toothed wedge belt.

Parameter

Model

(L)/mm

(W)/mm

(H)/mm

Weight (kg)

FMFG-2235

626

854

700

500

FMFG-2240

626

904

700

550

FMFG-2250

626

1004

700

610

FMFG-100*25

1834

1496

1718

2900

FMFG-125*25

2084

1496

1718

3400

FMFG-100*25*4

1964

1496

2258

5100

FMFG-125*25*4

2214

1496

2258

6000
